GLADIATOR Wheel Modification

Modifying your Gladiator's wheels requires comprehensive consideration of wheel size, material, and installation steps. Specific recommendations are as follows:



Wheel Size Selection

‌Calculating Rim Diameter‌: Calculate the rim diameter based on the tire size (e.g., 255/75R17), keeping the tolerance within ±3%. For example, tire height x 2 + diameter = rim diameter. Choose a wheel size that approximates this (e.g., 602mm).

‌Material Selection‌: Aluminum alloy wheels are lightweight and have good heat dissipation, making them suitable for urban driving; steel wheels are durable and better suited for off-road driving.

‌Manufacturing Process‌: Forged wheels offer superior strength and light weight, while cast wheels offer lower cost and greater toughness.

‌Recommended Brands: BEAST (wide-body wheels suitable for extended track widths), BLACKMUD (retro-style), MAT, TKX (stylish designs suitable for both urban and light off-road use), AGILITYFORCE (anti-slip wheels for enhanced off-road capability).

Modification Steps

‌Removing the Old Wheels‌: Remove the tires and the factory wheels.

‌Installing New Wheels‌: Align the wheel center hole with the hub to ensure a perfect fit. ‌

‌Adjusting Parameters‌: Check the ET value (offset) and the brake outer diameter to avoid affecting the odometer accuracy. ‌

Wheel specifications must be accurate: PCD5*127, ET-30~50, center hole 71.56, bolt size M14 x 1.5



Notes

After modification, test the brake system to ensure proper function. ‌

Tire width must match the wheel size; excessive width can cause binding. ‌

Snow chains are required for winter driving in snowy conditions. ‌

20-inch BLACKMUD wheels paired with 37-inch MT tires are suitable for off-road use, but the configuration should be adjusted based on actual usage.
